M1.6-.35 X 8 TORX T-5 PAN HD M/S SST
.16S8XPMS
| Item Id | .16S8XPMS |
| Description | M1.6-.35 X 8 TORX PAN T-5 M/S SST RoHS |
| Extended Description | |
| Packaging | EA |
| Brand | VARIED |
| Drive Size | T5 |
| Drive Type | Torx |
| Finish | Plain |
| Head Diameter (Max.) | 3.20 mm |
| Head Diameter (Min.) | 2.90 mm |
| Head Height (Max.) | 1.30 mm |
| Head Height (Min.) | 1.16 mm |
| Head Radius (Min.) | 2.50 mm |
| Head Type | Pan |
| Length | 8mm |
| Material | Stainless Steel |
| Meets (Standard) | ISO 14583 |
| Nominal Diameter | 1.60 mm |
| Recess Depth (Max.) | 0.47 mm |
| Recess Diameter | 1.42 mm |
| Thread Size | M1.6x0.35 |
| Thread Type | Metric Coarse |
| Units | Metric |
Contact Olander sales office for pricing on larger quantities, partial shipments, and secondary processes.
