Image for reference purposes only. Actual product may vary.
.3C10BHXS/TP
M3-.5 X 10 BUT HD TORX T/P PATCHLK SST
Alternate Codes: N/A
M3-.5 X 10 Button Head Torx T/P Patch Stainless Steel RoHS
Pricing per Unit
| 1-99 pcs | 100-249 pcs | 250-499 pcs |
|---|---|---|
| $1.131 | $0.720 | $0.661 |
Price is limited to stock on hand, if you would like to purchase more inventory, please call your Olander Inside Sales Representative at (800) 538-1500. We are happy to assist you!
In Stock
Maximum stock already in cart
| Length | 10mm |
| Thread Size | M3x0.5 |
| Finish | Plain |
| Brand | VARIED |
| Drive Type | Torx |
| Head Type | Button |
| Material | Stainless Steel |
| Units | Metric |
| Thread Type | Metric Coarse |
| Nominal Diameter | 3.00 mm |
| Fillet Transition Diameter (Min.) | 3.20 mm |
| Fillet Transition Diameter (Max.) | 3.60 mm |
| Key Engagement | 1.04 mm |
| Head Side Height | 0.38 mm |
| Torx Socket Size | 2.80 mm |
| RoHS | Compliant |
| Head Diameter (Max.) | 5.70 mm |
| Head Diameter (Min.) | 5.40 mm |
| Head Height (Max.) | 1.65 mm |
| Head Height (Min.) | 1.43 mm |
