  • Item Id: .3C5SPMN
  • Description: M3-.5 X 5 SLOT PAN HD NYL
  • Alternate Codes: 1900-0143, 73-H330-00
  • Quantity Discounts:
    1 to 99100 to 249250 to 499500 to 999Call For
    $0.346$0.182$0.144$0.133Larger Quantities
  • Extended Description:
  • Stock: In Stock
  • Packaging: EA
  • Quantity:
  • Additional Industry Cross Reference92942A805
    Body Diameter (Max.)3.00 mm
    Body Diameter (Min.)2.58 mm
    BrandVARIED
    Drive TypeSlotted
    FinishPlain
    Head Diameter (Max.)5.60 mm
    Head Diameter (Min.)5.30 mm
    Head Height (Max.)1.80 mm
    Head Height (Min.)1.60 mm
    Head Radius (Min.)1.20 mm
    Head TypePan
    MaterialNylon
    Meets (Standard)B18.6.7M
    Nominal Diameter3.00 mm
    Slot Depth (Min.)0.70 mm
    Slot Width (Max.)1.00 mm
    Slot Width (Min.)0.80 mm
    Thread SizeM3x0.5
    Thread TypeMetric Coarse
    UnitsMetric

Item Substitutes

Item IdDescription
.3C5SPMBPM3-.5 X 5 SLOT PAN HD BR PLNView Details
.3C5SPMNBM3-.5 X 5 SLOT PAN HD NYL BLK RoHSView Details
.3C5SPMSM3-.5 X 5 SLOT PAN HD SST RoHSView Details
