M4-.7 WING NUT SST RoHS
.4CWNTS
| Item Id | .4CWNTS |
| Description | M4-.7 WING NUT SST RoHS |
| Alternate Codes | 94545A220 |
| Extended Description | |
| Packaging | EA |
| Additional Industry Cross Reference | 94545A220 |
| Between Wing (Max.) | 7.0 mm |
| Between Wing (Min.) | 5.5 mm |
| Boss Diameter (Max.) | 9.0 mm |
| Boss Diameter (Min.) | 7.0 mm |
| Boss Height (Max.) | 4.6 mm |
| Boss Height (Min.) | 3.2 mm |
| Brand | VARIED |
| Material | Stainless Steel |
| Nominal Diameter | 4.00 mm |
| RoHS | Compliant |
| Thread Size | M4x0.7 |
| Thread Type | Metric Coarse |
| Type | Wing Nut |
| Units | Metric |
| Wing Height (Max.) | 11.0 mm |
| Wing Height (Min.) | 9.0 mm |
| Wing Spread (Max.) | 21.0 mm |
| Wing Spread (Min.) | 19.0 mm |
| Wing Thickness (Min.) | 1.1 mm |
Contact Olander sales office for pricing on larger quantities, partial shipments, and secondary processes.
