Item Categories

Defaultimage2 Image01



  • Item Id: .5C12XPMS
  • Description: M5-0.8 X 12 T-25 TORX PAN SST
  • Alternate Codes: 90362A125
  • Quantity Discounts:
    1 to 99100 to 249250 to 499500 to 999Call For
    $0.317$0.167$0.132$0.122Larger Quantities
  • Extended Description:
  • Stock: In Stock
  • Packaging: EA
  • Quantity:
  • Additional Industry Cross Reference90362A125
    BrandVARIED
    Drive SizeT25
    Drive TypeTorx
    FinishPlain
    Head Diameter (Max.)9.50 mm
    Head Diameter (Min.)9.14 mm
    Head Height (Max.)3.70 mm
    Head Height (Min.)3.52 mm
    Head Radius (Min.)8.00 mm
    Head TypePan
    MaterialStainless Steel
    Meets (Standard)ISO 14583
    Nominal Diameter5.00 mm
    Recess Depth (Max.)1.91 mm
    Recess Depth (Min.)1.52 mm
    Recess Diameter4.43 mm
    Thread SizeM5x0.8
    Thread TypeMetric Coarse
    UnitsMetric
