M8-1.25 X 16 PHIL FLAT VENTED GRIT
.8C16PFMS/VG
| Item Id | .8C16PFMS/VG |
| Description | M8-1.25 X 16 PHIL FLAT VENTED GRIT |
| Extended Description | BLASTED SST RoHS |
| Packaging | EA |
| Brand | VARIED |
| Drive Size | 4 |
| Head Diameter (Max.) | 15.80 mm |
| Head Diameter (Min.) | 15.37 mm |
| Head Height | 4.60 mm |
| Meets (Standard) | ASME B18.6.7M |
| Recess Depth (Max.) | 4.60 mm |
| Recess Depth (Min.) | 4.0 mm |
| Vent Hole Diameter | 2.00 mm |
Contact Olander sales office for pricing on larger quantities, partial shipments, and secondary processes.
