0-80 X 1/8 SLOT BIND SST RoHS
0F12SBMS
| Item Id | 0F12SBMS |
| Description | 0-80 X 1/8 SLOT BIND SST RoHS |
| Alternate Codes | 47-200946-01, 6000027-002, 91793A052 |
| Extended Description | |
| Packaging | EA |
| Additional Industry Cross Reference | 91793A052 |
| Brand | VARIED |
| Drive Type | Slotted |
| Finish | Plain |
| Head Diameter (Max.) | 0.126in |
| Head Diameter (Min.) | 0.119in |
| Head Height (Max.) | 0.032in |
| Head Height (Min.) | 0.026in |
| Head Oval Height (Max.) | 0.012in |
| Head Oval Height (Min.) | 0.008in |
| Head Type | Binding |
| Length | 0.12in |
| Material | Stainless Steel |
| Meets (Standard) | ASME B18.6.3 |
| Nominal Diameter | 0.060in |
| RoHS | Compliant |
| Slot Depth (Max.) | 0.018in |
| Slot Depth (Min.) | 0.009in |
| Slot Width (Max.) | 0.023in |
| Slot Width (Min.) | 0.016in |
| Thread Size | 0-80 |
| Thread Type | Unified Fine Thread (UNF) |
| Type | Machine Screw |
| Units | Inch |
Contact Olander sales office for pricing on larger quantities, partial shipments, and secondary processes.
