GP67-125X500-14R
GROOVE-PIN 1/8 X 1/2 TYPE 67 STL ZN CR3
Alternate Codes: 1520-0416, CL-1, DC-71, DC71, SPRING POST
RoHS
Pricing per Unit
| 1-99 pcs | 100-249 pcs | 250-499 pcs | 500-999 pcs | 1000-2499 pcs | Call For |
|---|---|---|---|---|---|
| $1.318 | $0.839 | $0.770 | $0.710 | $0.599 | Larger Quantities |
In Stock
| Material | Steel |
| Finish | Zinc Cr3 |
| Units | Inch |
| Nominal Diameter | 11 |
| Pin Diameter (Min.) | 0.123in |
| Pin Diameter (Max.) | 0.125in |
| Pin Type | TYPE-67 |
| Brand | GROOV PIN |
| RoHS | Compliant |
| Crown Height | 0.013in |
| Pin Size | 1/8in |
| Pilot Length | 0.031in |
| Shoulder Length (Min.) | 0.031in |
| Neck Diameter (Min.) | 0.078in |
| Neck Diameter (Max.) | 0.088in |
| Neck Radius | 0.31in |
| Shoulder Length (Max.) | 0.041in |
| Neck Width (Min.) | 0.059in |
| Neck Width (Max.) | 0.069in |
